Black Bear Low Head Room Electric Chain Hoist - YT Series
Free Shipping on Black Bear Hoist Products for a Limited Time. Web Sales Only
YHTD2 Low Headroom Electric Chain Hoist with TrolleyPerformance Low Headroom Series2 Speed Hoist & 2 Speed Trolley - 3 Phase
Black Bear Hoist Standard YT Series:
Black Bear Hoist are available in capacities from ½ ton through 5 metric tons, in either 230 or 460 three phase power. All three phase hoists are rated H4. Standard features include electrical upper / lower limit switch, 115 v control voltage, thermal overload protection, phase error relay (to prevent reverse phasing), instant acting motor brake, a mechanical load brake, a 4 button pendant pushbutton station + Emergency Stop button (with a drop of lift minus 3 feet) and a chain container. The pendant pushbutton is connected to the hoist with a quick connect.
*Trolley Option: *Wider Flange Widths Available.
Model
Capacity( Lbs.)
Speed(FPM)
TrolleyFlangeWidth(In.)
Chain Fall
Details
StandardLiftPendant Drop
YourPrice
YHTD2-050
1,100 lbs
Hoist Speed30 / 10 fpmTrolleySpeed79 / 26 fpm
3” ~ 5”
1
SpecificationsBrochure
10 ft - Lift7ft - Drop
$4,616
Contact Us for Availability
OperationManualParts list
15 ft - Lift12ft - Drop
$4,701
PartsOrder Form
20 ft - Lift17ft - Drop
$4,784
YHTD2-100
2,200 lbs
Hoist Speed26 / 9 fpmTrolleySpeed79 / 26 fpm
$4,751
$4,835
$4,919
YHTD2-200
4,400 lbs
Hoist Speed13 / 4 fpmTrolleySpeed79 / 26 fpm
4” ~ 6”
2
$5,302
$5,444
$5,585
YHTD2-300
6,600 lbs
Hoist Speed9 / 3 fpmTrolleySpeed79 / 26 fpm
5” ~ 7”
3
$6,051
$6,249
$6,447
Note:
1. Dimensions are approximate. If clearances are critical, ask for certified drawing.
2. All prices in U.S. Dollars F.O.B. Fontana, California Prepaid & Add
3. All prices subject to change without notice.
4. Non-Standard Lifts are Available, Please contact us for Details
5. Standard lift are 10 FT, 15 FT and 20 FT. Standard pendant drop is 3 FT shorter than lift. Standard power supply cord is 10 FT.
6. *Wider Flange Widths Available.
7. *Trolley Option: 1 Speed 60HZ Motor available at Speeds of 52FPM, 40FPM, 26FPM.
