Black Bear Electric Wire Rope Hoist - TU Series
Monorail - Underhung - 1 - 20 Ton
Double Reeve - (2 PD)* - 3 Phase 60Hz
1 Speed and 2 Speed Hoist/Trolley
Don’t see what you need. Give us a call or send us an e-mail with your specifications.Please call us or e-mail us for details. These descriptions may not be hoist specific.
Model
Capacity
Lift
Wire Rope(Dia.)
HoistSpeed(fpm)
TrolleySpeed(fpm)
Headroom
FlangeWidth
Approx. Weight(lbs.)
Hoist(hp)
Trolley(hp)
Single
Double
TUAH(D)-100DB
1 Ton
20
ø 6.3 mm
33.6 fpm3 hp33.6/11.2 fpm3/1 hp
49.2 fpm0.33 hp49.2/16.40.33/0.11 hp
19.8”
4”-11.25”
966 lbs.
30
1098 lbs.
40
1230 lbs.
TUBH(D)-200DB
2 Ton
ø 8 mm
28.6 fpm5 hp28.6/9.5 fpm5/1.7 hp
49.2 fpm0.54 hp49.2/16.40.54/0.17 hp
23.1”
1050 lbs.
1118 lbs.
1250 lbs.
TUCH(D)-300DB
3 Ton
ø 10 mm
22.1 fpm7 hp22.1/7.3 fpm7/2.3 hp
49.2 fpm0.54 hp49.2/16.4 fpm
27.4”
5” - 3”
1480 lbs.
1523 lbs.
1613 lbs.
TUDH(D)-500DB
5 Ton
19.1 fpm9 hp19.1/6.3 fpm9/3 hp
49.2 fpm1 hp49.2/16.4 fpm0.33/0.11 hp
28.1”
5” - 13”
1533 lbs.
1650 lbs.
1713 lbs.
TUEAH(D)-750DB
7.5 Ton
ø 12 mm
15.9 fpm11 hp15.9/5.3 fpm11/3.7 hp
52.5 fpm1.5 hp52.5/17.5 fpm1.5/0.54 hp
38.6”
6” - 14”
3020 lbs
3262 lbs
3170 lbs
3412 lbs
3320 lbs
3562 lbs
TUFAH(D)-1000DB
10 Ton
ø 14 mm
16.1 fpm15 hp16.1/5.3 fpm15/5 hp
42.7
3080 lbs
3300 lbs
3520 lbs
3570 lbs
3790 lbs
TUIH(D)-1500DB
15 Ton
ø 18 mm
14 fpm17.4 hp14/4.6 fpm17.4/5.8 hp
59 fpfpm2/0.67 hpm2hp59/19.7
57.2”
6”-14”
4570 lbs
4690 lbs
4620 lbs
4730 lbs
4790 lbs
4910 lbs
TUII(D)-2000DB*
20 Ton
ø 18 mm3 PD
10.4 fpm17.4 hp10.4/3.5 fpm17.4/5.8 hp
59 fpm3 hp59/19.7 fpm3/1 hp
69.9”
6020 lbs
6140 lbs
6390 lbs
6510 lbs
6760 lbs
6880 lbs
Note:
1. Dimensions are approximate. If clearance is critical, ask for certified drawings.
2. All prices in U.S. Dollars F.O.B. Fontana, California, Prepaid & Add
3. Prices Subject to Change without notice.
4. Hoist is dual voltage (230/460V) motor, and the standard set up is 460V
5. Trolley is dual voltage (230 / 460V) motor, and standard setup is 460V with DC100V Brake Coil through rectifier.
6. STD Controls consist of Hoist & Trolley Contactors, Transformer, Terminal Block, Control Box.
7. Control Voltage is 110V. Pendent / Radio / Inverter Control are available.
8. Custom Flange Widths are available. Refer to option page.
9. Upper / Lower Geared Limited Switch & Encoder are available.
